16 Channel NVR with 16 Plug & Play Ports.

UN1A-16X16L Features:

Connect up to 16 IP cameras in any combination with no special licenses required
- ‘Hands Free’ Plug-and-Play cameras on the 16 built-in PoE ports

- Power cameras with up to 30W each (802.3af PoE) from a total of 200W built in PoE power
Stream an aggregate bandwidth to the NVR of up to 256Mb/s from all connected cameras

Standard UN1A Features:

Onvif or other supported IP cameras* (*See list of manufacturers/models)
Select camera resolutions up to 6MP
Local HDMI/VGA monitor displays at up to 1920x1080
Employ digital zoom in both live view and playback for expanded view of fine details
Record based on schedule: Continuous, Motion, Event, Alarm, Combinations, None
Easy to use on-screen menus include digital zoom and instant playback of recent video
- Operate using front panel controls, wheel mouse or optional IR remote
Quickly locate and review event video
- Search by date/time, or preview images by pointing along a color coded timeline of record type

- Play based on results of extensive event/alarm log search

- Search for VCA events such as line crossing or area intrusion (requires compatible cameras)

- Use “Smart Search” to define an area of interest; the NVR quickly reviews recorded video to list instances of motion in that area for review by the operator
Optional arming schedule for action/notifications and alarms (e.g. ignore on-camera motion from specific cameras during normal business hours)
View, record and play main stream for detail, or sub-stream to conserve bandwidth and CPU resources
System automatically conserves resources by selecting sub-stream during multiple camera viewing
User selectable viewing optimization for image detail/fluency or motion
Choose up to 12Tb of internal Hard Drive storage, or record to external NAS/SAN
Option to enable pass thru access from LAN/WAN to cameras or to isolate camera network from LAN/WAN for increased security
Easy remote access: view NVR over Internet without programming router: built-in uPnP router NAT/port mapping forwards ports automatically (*Router must support/permit uPnP function)
Your choice of IE, Firefox or Safari browsers to view live or playback video, or to manage NVR
Unique Channel 0 remote stream displays user defined multi-view in the bandwidth of a single channel
View multiple live/playback video streams on Android/iOS apps, or get HD viewing from tablet specific app
Free Windows and MAC CMS Client for up to 64 live/4 playback views, manage and back up multiple sites
Two way audio support (compatible camera required) from NVR, web screens and CMS
Compact desktop chassis

Have Questions?

Get help from our experts

Our knowledgeable team is ready to answer any questions you may have and offer professional solutions tailored to your specific requirements.

Empowering Your Low-Voltage Projects with Quality Solutions

Invid Tech - NVR 16 Channel W/16 PoE

$640.00
